Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder
Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder

Eyes.sys 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N & 24-80VDC HSS57 Driver Power Cable Encoder

flash sale iconLimited Time Sale
Until the end
04
36
13

$55.97 cheaper than the new price!!

Free shipping for purchases over $99 ( Details )
Free cash-on-delivery fees for purchases over $99
See all stores
Please note that the sales price and tax displayed may differ between online and in-store. Also, the product may be out of stock in-store.
New  $93.28
quantity

Product details

Management number 211763500 Release Date 2026/04/04 List Price $37.31 Model Number 211763500
Category
  1. Industrial & Scientific
  2. Additive Manufacturing Products
  3. 3D Printer Parts & Accessories
  4. 3D Printer Motors

Motor Specifications: -Step angle: 1.8degree +/-5% -Phase: 2 phase -Rated voltage: 3.4V -Rated current: 4A -Resistance: 1.15 ohm +/-10%(At 20 degree centigrade) -Inductance: 3.6mH +/-20%/Phase -Hold torque: 3N.m -Insulation: B -Rotor inertia: 800g.cm2 -Weight: 1.4kg Driver Specifications: -Maximum peak current: 5A -Logic Signal Current: 1-16mA -Impulse response frequency: 200Khz -Micro-stepping driver: 200-51200ppr -Voltage: DC24-80V -Signal input: Support PUL/DIR and CW/CCW modes (difference) -Compatible 5-24V signal (Don't need a resistor) -Application temperature: 0-50 degree centigrade -Humidity: 40-90%RH -Shake: 10-55Hz/0.15mm -Pulse input frequency: 200kHz -Isolation Voltage: 500Mohm Packing List: -1 x 57HSZ3N Closed Loop Motor -1 x HSS57 Servo Driver -1 x 3m Power Cable -1 x 3m Encoder cable -1 x User Manual

  • 428oz-in Closed Loop Stepper Motor Kit, 3Nm/428oz.in Nema23 57HSZ3N Stepper Motor & 24-80VDC HSS57 Stepper Driver & Power Cable & Encoder Cable
  • HBS57 adopts advanced motor control DSP chip and vector loop control technology.
  • High precision and high speed. Low noise and little vibration, no step to lose.
  • Overload warning，which has the same reliability as the AC servo system.
  • Suitable for small and medium-sized automation equipments and instruments.
Voltage 24 Volts
Item Weight 5.24 pounds
Manufacturer Eyes.sys
Batteries Included No
Batteries Required No
Package Dimensions 7.91 x 7.05 x 2.91 inches
