ASI ASINPSM121-24 24V Super Compact DIN Rail Power Supply, 5 Amp, 120W Output, 90 VAC to 264 VAC Input

The ASINPSM121-24 is a high efficiency, space saving, single phase DIN rail power supply with compact dimensions that require less than 1. 5 inches of panel space.  Another industry first, key feature is the very wide range adjustable output which allows one power supply to cover the range of 3 power supplies. The overload capability of 150% or 7. 5 Amps for greater than 30 seconds will allow you to use this unique power supply in any application at 120 watts or 5 amps at 24 Vdc, the ASINPSM121-24 allows you to adjust the output from 12 to 28. 5 Vdc thereby allowing for use in 12, 15 and 24 Vdc applications. Additionally the wide range AC input of 90 to 264 volts insures that you can use this power supply in North America or anywhere else in the world. You can also easily adjust the output protection to either hiccup or constant current depending on your application requirements. With active PFC circuitry you are assured of optimal efficiency resulting in a long reliable operational life due to low dissipated power. A dry contact is also provided to allow you to wire up a remote DC OK status alarm. On the unit face is a red LED to indicate overload condition and a green LED for DC OK. The pluggable connections will save time and money during and after installation. Like all ASI power supplies this power supply carries a cULus listed making sure that your UL panel maintains its listing. Other features include short circuit, over temperature, input and output overvoltage protection. The overload limit is 7. 5 A for greater than 30 seconds.

• Smallest 120 W DIN rail power supply on the market
• Wide range adjustable output, 12 to 28. 5 Vdc
• User settable limitation mode: hiccup or constant current limitation
• Pluggable connections simplify installation
• Short circuit, over voltage, and over current protection
