LK Voltage Regulator Rectifier for Victory Cross Country 2010-2017,Cross Roads 2010-2014,Hard Ball 2012-2013, Magnum 2015-2017,Vision 2008-2017,Powersports Alternator Rectifiers Replacement

LEAPING KNIGHT Voltage Regulator Rectifier with Wire for Victory Cross Country 2010-2017 / Cross Roads 2010-2014 / Hard Ball 2012-2013 / Magnum 2015-2017 / Vision 2008-2017 / OEM PART NUMBER:4011959;4012238;4012717Replacement for Victory Cross Country -- 2010-2017Victory Cross Roads -- 2010-2014Victory Hard-Ball -- 2012-2013Victory Magnum -- 2015-2017Victory Vision -- 2008-2017Specifications:Material: High Quality AluminumCondition: 100% Brand NewFixation holes center to center: 3.26 inchWires length: 12.59 inchNumber of plugs: 2 , Number of pins: 5Minimum Charging Voltage: 14.5V +/- 0.5VVoltage Regulator Rectifier Installation and Maintenance Instructions:1.We should install the rectifier in a location with good ventilation and good heat dissipation, because the rectifier will produce high temperature when working,and poor heat dissipation will damage the rectifier.2.The voltage regulator should be installed tightly on the frame to facilitate heat conduction.3.Do not press other wires between the voltage regulator and the frame.Installation Steps:1.Connect the AC input line, and the positive and negative outputs are not connected.2.Start the motorcycle and measure the positive and negative output voltages.3.When the voltage range is reasonable, plug in the positive and negative wires.4.Then test the voltage of the battery or the voltage of the positive and negative of the rectifier to see if it is within a reasonable range,if the voltage range is unreasonable, stop using it and give us feedback.

• FITMENT:The voltage regulator is direct replacement for Victory Cross Country 2010-2017;Victory Cross Roads 2010-2014;Victory Hard-Ball 2012-2013;Victory Magnum 2015-2017;Victory Vision 2008-2017. OEM PART NUMBER:4011959;4012238;4012717
• OVER CHARGING PROTECTION & FULL WAVE RECTIFICATION:Output voltage is stable at 14.5V±0.5,the regulator rectifier with male plug, which can prevent over-charging and improve charging capability,saving and stabilizing current.
• OVERHEAT PROTECTION:This voltage regulator has overheat protection,help to dissipate excess voltage,prevent over-charging battery,improve heat sink and charging capabilities.Good heat dissipation for our motorcycle.
• SAFER RELIABLE VOLTAGE REGULATION:100% quality assurance tested.The rectifier is made of high quality aluminum and copper wire, provide good heat dissipation and extend service life.Durable and long lasting.
• EASY TO INSTALL: The rectifier for Cross Roads is value for money,easy to install, just plug and play. Fixation holes center to center: 3.26 inch.Wires length: 12.59 inch
