U9845 4-Channel Impulse Winding Tester Meter - Transformer Motor Surge Tester with Coil Testing - Voltage Range 100V-5000V
4.3 (130 items)
Limited Time Sale$855.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211806160 | Release Date | 2026/04/04 | List Price | $570.00 | Model Number | 211806160 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- U9845 Impulse Winding Tester is a versatile winding testing device with a pulse voltage of 100V~5000V at 10V steps, 5%±10V. U9845 test systems utilize switching components controlled by high stability, high-voltage impact power and thyristor modules. This configuration dramatically increases stability, reliability and measurement precision during testing.
- U9845 can be operated over four high-voltage channels and through one of four waveform comparison methods: area, differential area, corona and differential phase. U9845 impulse winding testers possess an advanced 32 bit CPU and a memory depth of 6500 bytes.
- Two-channel comparison test, dispense with standard waveform acquisition; 65k color 7’’ TFT high definition display screen, selectable Chinese and English interfaces;
- Waveform sampling rate:100Msps; memory depth: 6500bytes; Max. Test speed: 12 meas/sec; Strong corona analysis and extraction function (several corona modes and corona display function) to excavate potential defective insulation of products
- Instrument parameters automatic storage and boot-up file load function; Vertical exaggeration, horizontal zoom and movement of waveforms for detail observation
- Sample average function, average processing of 32 standard waveforms; Automatic standard acquisition mode to select suitable sampling rate; Destructive testing bring the right test voltage for you
- Fast test mode can make real-time change of impulse voltage and sampling rate; Imposed demagnetized impulse to ensure the conformity of the tested waveforms.
- 20000 pieces of historical measured data storage and discrimination statistics function; can be saved to the U-disk; Directly save the screen pictures (BMP, GIF, PNG) or waveform data to U-disk through SAVE key.
- System firmware upgrade through U-disk.
- Foot switch interface for easy and fast measurements.
| UPC | 520361367678 |
|---|---|
| Color | Grey |
| Model | U9845 |
| Brand Name | M&A INSTRUMENTS |
| Style Name | Compact |
| Manufacturer | M&A INSTRUMENTS INC |
| Power Source | Corded Electric |
| Measurement Type | LCR Meter |
| Specification Met | Ul 61010-1, Iec 61010-2-030 |
| Included Components | U9845 Tester |
| Minimum Operating Voltage | 100 Volts |
