SMA20 RTK PPK GNSS Receivers GPS Land Surveying Equipment Rover Base Collector, Free Software,Calibration Free, NOAA Certified1cm Accuracy,1408 Channels, Connect with UAV/Drone,for Topographic and GIS
4.8 (137 items)
Limited Time Sale$398,927.34 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 212343231 | Release Date | 2026/04/06 | List Price | $265,951.56 | Model Number | 212343231 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Advantages: ①Static &RTK base dual mode,when static surveying simultaneously work as RTK base, enable SMA20 multiple surveying mode capability and high accuracy ②NOAA certification: SMA20RTK is antenna name of NOAA registered ③PPK enabled suitable for challenge environment,forest,canyon.. in a long distance 25km ④PPP method by Galileo HAS correction ⑤Rinex logging enabled which can export rinex files directly to PC ⑥CORS network connection supported by login a CORS account on collector
- Capability: Full-Constellation RTK GPS Land surveying equipment Rover+Base+Collector(Software activated). ①Max 25km distance between rover base by PPK; ②1cm RTK accuracy,0.25cm static accuracy ③5-8km UHF distance by RTK ④max. angle 60°tilt, 30° tilt 2.5cm accuracy (horizontal) ⑤long endurance battery,10hours for base,15hours for rover under continuous work of each battery charge ⑥2.5cm accuracy by PPK method,compatible with SMA26 static equipment; 2.5cm accuracy by CORS
- ⑦SMA20RTK GNSS Receiver offers versatile surveying modes to adapt to various project requirements and environments ⑧Data output format: RTCM3.X (input&. output), NMEA-0183 (input&. output), CMR (input), RTCM2.X (input) ⑨Multiple constellation adaptable to any country and suitable for use in various complex and challenging environments
- RTK Connection: Rover+Base:Connect Collector with GNSS receiver by BT to set rover and base at the same protocol and frequency till RTK fixed. Or Rover+CORS: login CORS account on software till RTK fixed
- Application: The SMA20 RTK GNSS receiver provides the accuracy needed for a wide range of surveying and engineering applications, including topographic surveying, geographic surveying, engineering surveying, agriculture field measurement, mine surveying, construction surveying
| Brand | SMAJAYU |
|---|---|
| Map Types | Topographical |
| Model Name | SMA20 RTK-400MHz |
| Screen Size | 5.5 Inches |
| Display Type | touch screen |
| Manufacturer | SMAJAYU |
| BuiltIn Media | 400MHz Antenna |
| Mounting Type | Handheld |
| Touch Screen Type | Capacitive |
| Additional Features | PPK, PPP, NOAA Certification, Multi-Satellite System Support |
| Battery Average Life | 2 days |
| HumanInterface Input | Touchscreen |
| Are Batteries Included | Yes |
| Connectivity Technology | Bluetooth, Wi-Fi |
| Memory Storage Capacity | 64 GB |
| Supported Satellite Navigation System | BeiDou, GLONASS, GPS, Galileo |
