Davitu DC Motor - 12V/30W DC Gear Motor Electric Permanent Magnet Permanent Magnet DC Motor 3000/3200RPM model XD3D30-12GN-32S - (Speed(RPM): 30RPM)

12V/30W DC Gear Motor Electric Permanent Magnet Permanent Magnet DC Motor 3000/3200RPM model XD3D30-12GN-32SFeatures:The motor no-load speed is 3000rpm and load speed is 3200rpm After strict safety electromagnetic testing, the insulation grade is Class B. Compared with traditional motors, permanent magnet motors have lower power consumption and longer service life. Low heat generation, stable motor operation and reliable performance. Metal gears, large torque. Specifications: Model: XD3D30-12GN-32S Voltage: 12 V Power: 30 W Motor no-load speed: 3200 RPM No-load current of the motor: 1.0 A Motor load speed: 3000 RPM Motor load current: 3.5 A Torque: 0.8 kg.cm Insulation class: Class B Motor size: 70*70*174mm Reducer shaft size: 8mm*29mm (diameter* length)Model(Optional) Reduction ratio Gearbox output shaft speed #1 3 1067RPM #2 5 640RPM #3 7.5 430RPM #4 10 320RPM #5 12.5 260RPM #6 15 210RPM #7 18 180RPM #8 20 160RPM #9 25 130RPM #10 30 110RPM #11 36 90RPM #12 50 65RPM #13 60 50RPM #14 75 40RPM #15 100 30RPM #16 150 20RPM #17 180 17RPM #18 200 16RPM Package list: 1 * MotorNote: The actual product color may deviate from the photo due to light. There may be a slight deviation in the measurement of product. If you are satisfied with our products, Pls give us 5 Starsand services. If you have any problems with our items or services, We will do our best to solve any problem and provide you with the best We maintain high standards of excellence and request that you contact us immediately BEFORE you give

• Speed(RPM): 30RPM
• The motor no-load speed is 3000rpm and load speed is 3200rpm
• After strict safety electromagnetic testing, the insulation grade is Class B.
• Compared with traditional motors, permanent magnet motors have lower power consumption and longer service life.
• Low heat generation, stable motor operation and reliable performance.
