GPS Receiver Module RS232 GNSS GLONASS Dual Mode VCC 12V Industrial Control Quality DB9 Female GN200GRV12

TOPGNSS RS232 GNSS receiver module GN200GRV12, compatible with GPS and GLONASS dual-mode.Features UBX-M8030-KT GNSS chip, L1 frequency (1575.42 MHz), and supports GPS/QZSS L1 C/A, GLONASS L1OF, BeiDou B1, and SBAS (WAAS, EGNOS, MSAS); Galileo E1B/C support included.Default navigation output protocol is NMEA 0183 v2.3 and v4.x.Default output sentences: GGA, GSA, GSV, RMC; additional supported sentences: VTG, GLL, TXT.Binary and NMEA configuration commands available.Baud rate configurable from 1200 to 115200 bps; default is 9600 bps.72-channel tracking capability.Tracking sensitivity: -160 dBm; acquisition sensitivity: -157 dBm.Time-to-first-fix: cold start 29 seconds average, warm start 28 seconds average, hot start 1 second average.Horizontal positioning accuracy in autonomous mode.Power supply: 12 V DC.Connector: DB9 female.

• Model GN200GRV12 supports dual-constellation positioning with GPS and GLONASS for improved satellite availability and in challenging environments
• Designed for industrial control applications, this module operates stably under wide temperature ranges and electromagnetic interference conditions common in factory automation and heavy machinery
• Features a standard DB9 female connector with RS232 serial interface for straightforward integration into legacy and modern control systems
• Rated for 12V DC input voltage, compatibility with common industrial power supplies and vehicle electrical systems
• Delivers NMEA 0183 output data at configurable baud rates, supporting real-time location tracking and telemetry in logistics, marine, and surveying
