0V-100V 30A 45A 50A Adjustable Lifepo4 Battery Charger 88.2V 92.4V 96.6V(30V-100V 45A,220V AU)

This is a modified product. Do not order if you are mindWhen charger work in110V Country,working Current will reduce half.When buying ,need to leave message that you battery votage and current,so that we can modify the right to you.FeaturesAC input: 110V or 220VOutput power: 2700W--4000WDC output voltage: Customized as needWeight:about 3.5kgSize:29*12*4cmEfficiency: >93%Materail:Aluminum CaseUse for : li ion/lifepo4/Lead AcidbatterysCharging Mode:CC, CV, TrickleProtect Characteristic1.Short-circuit protection2.Over-current protection3.Over-voltage protection4.Reverse Polarity Protection5.Over-temperature protectionWork Conditions:Ambient temperature: -5 - 40RH: 5 - 95%Max. altitude: 10000 meterCooling: chargers use of forced air cooling system. Under dustless and ventilated conditions, the full load temperature rise not exceeding 40.Storage conditionsAmbient temperature: -40 - 70RH: 0 - 95%Max. altitude: 20000 meters.Charge current regulationHow much current the battery can charge , we must first understand what the charge and discharge rate is, in C;Charging rate = charging current ÷ battery capacityUsually our lithium batteries can withstand a charging rate of 0.5C, and some high-rate cells can withstand 1C charging; for example, calculating the current of a 60AH battery with standard 0.5C charging is:Charging current = capacity X rate = 60X0.5=30A.So 60AH lithium battery can withstand 30A current charging.The formula for calculating battery charging time:Charging time = capacity ÷ charging current = 60AH÷30A=2HCommon problemHow come the voltage regulation has not changed?Answer: The voltage knob is turned counterclockwise seven or eight times and it will come down.How can the casing leak electricity?Answer: All metal shell electrical appliances are equipped with triangular plugs, in order to ground the shell, as long as your socket is grounded, there will be no leakage. If there is no way to ground it, drying of shoes can also be solved.Will it stop by itself when fully charged?Answer: Adjust the voltage value to charge, it will stop when it is full.Is it normal that the heat sink is a little hot?Answer: High-power charging will definitely get hot. The fan is a temperature-controlled fan. The higher the temperature, the faster the fan rotates. The charger also has over-temperature protection. If the temperature exceeds the specified temperature, it will reduce the power by itself. Use it with confidence.==========Converter Type : DC-DC ConverterItem Weight : 3.8KGItem Height : 40MMItem Width : 113MMItem Length : 280MMOrigin : Mainland China

• Features
• AC input: 110V or 220V
• Output power: 2700W--4000WDC output voltage: Customized as need
• Weight:about 3.5kg Size:29*12*4cm Efficiency: >93%
• Materail:Aluminum CaseUse for : li ion/lifepo4/Lead Acidbatterys Charging Mode:CC, CV, Trickle
