3 Row Aluminum Radiator Shroud Fan Kits for 1932 FORD MODEL A/B HI BOY HOT ROD CHEVY V8 Downflow Radiador Automotive Replacement Engine Radiators

Package Include: 1 X 3-Row AA5052 Aluminum Radiator 1 x CNC Machined Radiator 1.3Bar Cap 1 X AA5052 Aluminum Shroud 1 X 14" Fan (Includes mounting kits) 1 X Thermostat Relay Kits Vehicle Fitment: for 1932 FORD Model HI-BOY Grill Shells Hot Rod CHEVY ENGINE Radiator Size: High Performance Racing Spec. 3-Row of tubes Core Racing Design Core Material: AA5052 Aluminum Includes CNC machined filler neck and cap Core Dimensions: 17.25"(H) x 17.03"(W) Overall Dimensions: 22-1/2" (H) x 17-1/2"(W) x 3-1/8" (T) Upper Inlet 1-1/2" located on the Center Lower Outlet 1-3/4 located on the Passenger side OEM Style Brass Petcock Drain. Please Check the Size Before You Buy! Fan Specifications： Maximum Fan CFM: 2200±200 FAN DIAMETER X HEIGHT X THICKNESS:14.05" X 14.05" X 2.5" Number of Blades: 8 blades (Plastic) Maximum Fan RPM/ Amp Draw :2,250 rpm / 12.70 amps Thermostat Kit: Universal fit for any automotive vehicle and electric fan. Activates by grounding electric fans at preset temperature. 185'F turn-on temperature, 165'F turn-off temperature. 3/8" NPT thread-in brass probe included. Probe typically threads into radiator, water outlet or manifold. Thermostat Relay Kit Instructions： RED + connect directly to battery. WHITE wire to ignition switch power source. BLACK goes to thermos switch. BLUE wire goes to the Fans. About MIONLVE:If you have any questions, please feel free to contact us, we will solve it for you.

• 【Compatibility】Compatible with 3 Row Radiator Shroud Fan for 1932 Ford Hi Boy Hot Rod Grill Shells Chevy V8 Please confirm the compatibility with your vehicle before ordering. Thank you!
• 【Radiator Size】Core size: 17.25"(H) x 17.03"(W); Overall size: 22-1/2" (H) x 17-1/2"(W) x 3-1/8" (T); Inlet size: 1-1/2" located on the Center; Outlet size: -3/4 located on the Passenger side
• 【Material】 All-aluminum design , the corrugated aluminum fins and TIG-welded construction ,is welded in vacuum brazing furnace no epoxy, providing unparalleled performance. This aluminum radiator is at least 35%-40% more efficient than stock ones.
• 【High Performance】 3-Rows downflow radiator, 100% leak and durability tested; built with high-density multi-louvered fins to improve cooling efficiency and ensure durability in extreme cold weather.
• 【Easy to Install】 Light weight direct bolt-on oem fitment or replacement. Carefully crafted to exceptional OEM standards for precise fit.
