Go Kart Wheels 145/70-6 6 Inch Hubs Spindles 30" Rear Differential Axle Kit Motor Controller Steering Wheel Switch for ATV UTV Drift Trike Golf Cart Quad Buggy Dune Moped Mower Four Wheeler Tricycle

145/70 - 6 inch Wheel: Color: Black Material: Nylon Size: 145/70-6 Rim: 6 inch Pattern: 3 Bolts Wheel Tall: 360mm (14.17 inch) Wheel Width: 135mm (5.31 inch) Bolt Space: 78mm (3.07 inch) Max load 160lbs (70kg) 4PR Rating tubeless 24 P.S.I max to seat beads 10 P.S.I operating pressure Not for highway use Rear Differential Axles Kit: Condition: brand new Material: metal Color: black Total length: 760mm/ 29.92 inch (plz check the size picture for the dimension specification) Fitment: for ATV UTV Go Kart Golf Cart Buggy Quad Lawn Mower Drift Trike Tricycle 4 Wheeler Brushless Differential Motor: Condition: brand new Material: metal Color: black Gear Ratio: 9.5:1 Torque: 2.62Nm Rated Speed: 4800rpm Rated Voltage: 48V Rated Output: 1000W Rated Current: 18-35A Max Discharging Time : 140mins High Speed: 20mph Medium Speed: 16mph Low Speed: 10mph( under the load of 198lbs, and the weight of the bike is 154lbs) Protect Rate: IP54 Insulation Level: B Wire Length: 1320mm (51.97 inch) Motor length: 250mm (9.84 inch) Brushless Controller: Condition: 100% Brand New Nominal Voltage: DC 36V/ 42V/ 48V/ 52V/ 58V/ 60V/ 64V/ 72V/ 84V Rated Power: 1000W-2200W Matching Motor: DC Brushless Motor Under Voltage Protection: 20V Max Current: 40A-50A Brake: Low/ high electric level Motor Phase Angle: Automatic identification Features: 18 Tube,Square Wave Size: 238 x 84 x 41mm/ 9.4 x 3.3 x 1.9 inch Rear brake assembly: Brand New Hydraulic Front Disc Brake Twin Calipers with Master Cylinder & Brake Pads Brake System Fit 110cc 125cc DIY Quad Bike ATV Buggy High compression hydraulic cable Come with brake pads 3 Stud Front Wheel Hubs: Color: Gold Material: Metal Diameter Of Centre Hole: 17mm/0.66 in Distance Between Hub Mounting Holes (Centre To Centre): 78mm/3.07 in Front Wheel Steering Knuckle Spindle: Material: Aluminum Alloy Color: Gold Diameter Of Centre Hole: 17mm/0.67 in Steering Wheel: This universal go-kart part is also compatible with other brands and models of go-karts from Hammerhead, Roketa, TaoTao, JCL, SUNL, and others. It may be the perfect replacement steering wheel for the old wheel on your go-kart or dune buggy. Diameter: 270mm (10.6") Motorbike Battery: ITEM NO: 6-DZM-12 Amperage: 12AH Voltage: 12V Weight: 3.8kg(8.36lbs) Size: 5.9"(150mm) x 3.9"(100mm) x 3.8"(98mm) Features: High Performance Battery 100% Maintenance Free Shock and Vibration Resistant Spill-Proof Design ensures high discharge rate, wide operating temperatures, long service life and deep discharge recover Can be mounted in any position Long lasting high performance in high and low temperatures Package includes: 1 x 30 inch Rear differential Axle Kit 1 x 48V 1000W Differential Motor 1 x Brake Caliper Assembly 1 x 36V-84V 1000W-2200W Brushless Motor Speed Controller 4 x 145/70-6 powersport Wheels 1 x steering wheel gear rack pinion set 1 x Steering Wheel 2 x 3 Stud Front Wheel Hubs 2 x Front Wheel Steering Knuckle Spindles 1 x brushless wiring harness 1 x ignition key switch 1 x 3 speed switch 1 x throttle pedal 1 x brake switch 1 x charging port 1 x terminal block 1 x forward reverse switch 1 x power indicator 1 x 25ah air switch 4 x 12V 12AH Batteries 3 x Copper Battery connect cables 1 x Battery Charger

• 145/70-6 6 inch Go Kart Wheel: 360mm (14.17 inch) in height, 135mm (5.31 inch) in width; Max load 160lbs (70kg); 4PR Rating tubeless; 24 P.S.I max to seat beads; 10 P.S.I operating pressure
• 760mm 30" Differential Axle Kit: Made from high-strength metal, this rear differential split axles kit is built for toughness and durability to handle rugged terrains and heavy loads; With a total length of 760mm (30 inches); Complete Axle Kit Includes 2 rear differential split axles, brake disc, and hubs, providing all necessary components for a smooth and easy installation
• DC 48V 1000W Brushless Differential Motor Gearbox: Rated at 1000W with a torque of 2.62Nm and a speed of 4800rpm; Rated voltage of 48V with a current range of 18-35A for stable operation; Efficient Gear Ratio 9.5:1; Max discharging time of up to 140 minutes
• Powerful Compatibility Controller: Suitable for DC Brushless Motors with a rated power range of 1000W to 2200W, supporting nominal voltages from DC 36V to 84V; Equipped with under voltage protection at 20V and capable of handling a maximum current of 40A-50A for enhanced safety
• 12V 12AH Sealed Lead Acid (SLA) Battery: Rechargeablem maintenance free battery, High discharge rate, wide operating temperatures, long service life and deep discharge recover, Can be mounted in any position, Shock and Vibration Resistant; 150 x 100 x 98 mm (5.9 x 3.9 x 3.8 inch) in size
• Wide Application: Universal for Electric Scooter Go Kart ATV UTV Drift Trike Golf Cart Quad Buggy Dune Moped Lawn Mower Four Wheeler Tricycle Mobility Offroad Motorcycle
• Package Includes: 1 x 30 inch Rear differential Axle Kit; 1 x 48V 1000W Differential Motor; 1 x Brake Caliper Assembly; 1 x 36V-84V 1000W-2200W Brushless Motor Speed Controller; 4 x 145/70-6 powersport Wheels; 1 x steering wheel gear rack pinion set; 1 x Steering Wheel; 2 x 3 Stud Front Wheel Hubs; 2 x Front Wheel Steering Knuckle Spindles ; 1 x brushless wiring harness; 1 x ignition key switch; 1 x 3 speed switch; 1 x throttle pedal ; 1 x brake switch; 1 x charging port; 1 x terminal block; 1 x forward reverse switch; 1 x power indicator; 1 x 25ah air switch; 4 x 12V 12AH Batteries; 3 x Copper Battery connect cables; 1 x Battery Charger
