Enttec D-Split 70579 DMX 4 Port Isolated Splitter / Isolator (5-Pin)
4.3 (131 items)
Limited Time Sale$79.80 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 215948834 | Release Date | 2026/04/19 | List Price | $53.20 | Model Number | 215948834 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The D-SPLIT is a 1 to 4 DMX 512 splitter, allowing you to send your signal in different directions or to increase the number of fixtures that you can send your signal to (DMX signal is limited to running through 32 fixtures). The D-SPLIT can provide more flexibility in connecting DMX controlled devices. Instead of having to make them all fit within a single daisy chain, each of the four outputs from the D-SPLIT can be the start of its own chain, and multiple DSPLITs can be linked together if needed. Technical Specifications: 4 DMX outputs: All 5-Pin DMX outputs Lightweight and portable. 1 DMX input: D-Split offers the flexibility of 3-Pin and 5-Pin male connectors for connection to only 1 DMX input. All outputs are optically isolated (protects against up to 1000V of stray voltage). DMX512-1990 compatible. Controls up to 512 channels Daisy chain via input ports without utilizing any output ports LED indicators when powered. External power supply (included). DMX pass through Wide voltage range Stealth design 3-year warranty Box Contents: D-Split Power supply with UK/EU/S/AU adaptor TS35 DIN clip & 2x mounting screws
- Four DMX outputs: All 5-Pin DMX outputs
- One DMX input: 3-Pin and 5-Pin male connector for connection to only 1 DMX input
- All outputs are optically isolated (protects against up to 1000V of stray voltage)
- Controls up to 512 channels
- DIN rail mounting solution
| Color | Black |
|---|---|
| Shape | Rectangular |
| Voltage | 12 Volts |
| Amperage | 0.5 Amps |
| Brand Name | Enttec |
| Style Name | Modern |
| Unit Count | 1.00 Count |
| Item Weight | 5.6 Ounces |
| Finish Types | Black |
| Manufacturer | ENTTEC |
| Model Number | 70579 |
| Power Source | Corded Electric |
| Material Type | Stainless Steel |
| Mounting Type | DIN Rail Mount |
| Shade Material | Acrylonitrile Butadiene Styrene |
| Light Source Type | Led |
| Batteries are Included | No |
| Number of Light Sources | 4 |
| Light Source Special Features | Optically isolated outputs, DIN rail mounting solution |
| Manufacturer Warranty Description | 2-year warranty. |
| Global Trade Identification Number | 09351074003451 |
| Maximum Compatible Light Source Wattage | 6 Watts |
