KingVal Replacement 3650 5900KV Brushless Motor Shaft 3.175mm with 80A Brushless ESC and Program Card Combo Compatible with 1/10 RC Car
4.2 (116 items)
Limited Time Sale$41.81 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 216429573 | Release Date | 2026/04/19 | List Price | $27.87 | Model Number | 216429573 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Features:*4 Poles 12 Slots Hi-torque Motor Design*CNC machined 6061 T6 billet aluminum heatsink can*High purity copper windings maximizes efficiency*High RPM ABEC5 oversized bearings*Universal fit, fits all 1/10 brushless cars-multi-mounting system for M3 screws*Precision balanced rotor,smoothness for best reliability and maximum RPM*Stator - Super Thin(0.35mm) Laminations*Removable/Replaceable rotor*Precision engineered for maximum energy conversionSpecifications:Brand: KingValProduct: 3650 Sensorless MotorMotor Size: ø36x50mmKV(RPM/Volt): 5900Watts: 900Max Voltage: <8.4VMax Amps: 107ARotor Poles: 4IO: 5.2AResistance: 0.0043Max RPM: 50000Shaft Diameter: 3.175mmLength of extend shaft: 15mmConnector: 4.0mm goldN.W: 180g80A ESC:Continuous current: 80ABurst current: 480APower supply: 2~4 cells Lipo battery, 4~12 cells NiMH batterySuitable Car: 1/8 carSuitable Brushless Motor: ≥5.5TResistance: 0.0005ohmBEC output: 6.1V/3A (Switch Mode)Dimension: 41x51x36mmWeight: 113gProgram Card Spec:Low Voltage Cut-Off: 3.1V/2.9V/2.7V/0VStart mode: Medium, Soft, StrongMax brake force: 25%,50%,75%,100% (80A/120A); 50%,25%,75%,100% (25A/35A/45A/60A)Max reverse force: 25%,50%,75%,100%Neutral range: 9%,6%,12%,Work StatesN.W: 23gPackage List:1 x 3650 Brushless Motor1 x 80A Brushless ESC1 x Program Card1 x Manual
- 4 Poles 12 Slots Hi-torque Motor Design
- CNC machined 6061 T6 billet aluminum heatsink can
- High purity copper windings maximizes efficiency; High RPM ABEC5 oversized bearings
- Universal fit, fits all 1/10 brushless cars-multi-mounting system for M3 screws
- Precision balanced rotor,smoothness for best reliability and maximum RPM
| Model | 3.175mm 3650 5900KV+80A+PC |
|---|---|
| Speed | 5900 RPM |
| Voltage | 8.4 Volts |
| Brand Name | KingVal |
| Horsepower | 900 Watts |
| Item Weight | 330 Grams |
| Manufacturer | KingVal |
| Material Type | Aluminum |
| Shaft Diameter | 3.18 Millimeters |
| Item Dimensions W x H | 1.42"W x 1.42"H |
