EZROAD 73060G01 36V 500A ITS DC Motor Speed Controller Compatible with E-Z-GO EZGO 95-04 TXT Golf Cart, 99-04 Shuttle 950 Series XI-875 881 Workhorse MPT 1000 Compatible with Curtis Programmable

Part Number: 73060G01 Compatible with E-Z-GO the following models: Compatible with E-Z-GO TXT 1996-2004 (Fleet) Compatible with E-Z-GO Electronic Medalist 1997-1999 (PTV) Compatible with E-Z-GO Shuttle 950 Series 1999-2004 (PTV) Compatible with E-Z-GO XI-875/881 1998-1999 (Industrial) Compatible with E-Z-GO Workhorse/MPT (Multi-Purpose Truck) 1000 Specification: Voltage: 36V Current: 500A Throttle Type: ITS Dimensions: 146mm x 222mm x 70mm (5.75 inch x 8.75 inch x 2.8 inch) Note: This unit is pre-configured for 36V/500A with ITS throttle input. To adapt it for other models, reprogramming via handheld programmer is required. Key features of the EZROAD 73060G01 controllers include: 1. Infinitely variable drive and brake control 2. Power MOSFET design provides high efficiency (for reduced motor and battery losses) and silent operation. 3. High pedal disable (HPD) function monitors throttle status during turn-on and prevents operation until throttle has been returned to neutral [optional feature]. 4. Thermal protection and compensation circuit provides both undertemperature and overtemperature cutback, as well as steady current limit throughout the entire operating range. 5. Under voltage cutback function protects against low battery voltage, including low voltage caused by external loads Pot fault circuit shuts off controller if pot wires open. 6. Simple installation with no adjustments required. 7. Tin-plated solid copper bus bars. 8. Push-on connectors for control wiring. Connections: High current connections: These controllers have four high-current busbars: B+, B-, A2, and M-. The busbars are tin-plated solid copper. B+ Battery+ and motor armature. (plug diode -) B-B- A2 Motor armature and field (plug diode +). M- Motor field (controller output). Cables used for the battery and motor connections must be heavy enough to carry the high current required. A minimum size of 25 mm2 (#4 AWG) is recommended. Connections to the controller busbars should be made with lugs suitable for the cable used, fastened by M8 bolts and nuts. When tightening the bolts, two opposing wrenches should be used. Failure to use the double-wrench technique could cause undue strain to be placed on the internal connections, and could also result in cracked seals around the busbars. Low current connections: This is an upgraded controller featuring a J4 connector, designed for status LED indication or programming interfaces. These controllers have five low-current connections: four 6.35 mm push-on terminals (J1, J2, J3, and J5), and one 4-pin connector (J4). J1: Keyswitch. J2: Wire 1 of 2-wire throttle; Pot High of 3-wire or ITS throttle. J3: Wire 2 of 2-wire throttle; Pot Wiper of 3-wire throttle; Pot Low of ITS thottle; or electronic throttle input. J4: 4-pin connector, an external Status LED or a programmer can be connected to J4. Note: When J4 is used for a Status LED, a jumper must be added between pins J4-1 and J4-4. J5: Reverse signal output / main contactor coil driver. This is an aftermarket part, not an original. It is compatible with your device and will function like the original. Looking for parts compatible with E-Z-GO? Our inventory includes a comprehensive range of compatible parts. Simply enter your model or part number to find the exact match in our store. Our product specialists are available for support.

• Part Number: 73060G01
• 36V, 500A, ITS, Programmable. Note: This unit is pre-configured for 36V/500A with ITS throttle input. To adapt it for other models, reprogramming via handheld programmer is required.
• Compatible with E-Z-GO TXT 1996-2004 (Fleet)
• Compatible with E-Z-GO Electronic Medalist 1997-1999 (PTV)
• Compatible with E-Z-GO Shuttle 950 Series 1999-2004 (PTV)
• Compatible with E-Z-GO XI-875/881 1998-1999 (Industrial)
• Compatible with E-Z-GO Workhorse/MPT (Multi-Purpose Truck) 1000
• This is an aftermarket part, not an original. It is compatible with your device and will function like the original.
