Mini PCI-E to PCI-E Express 1X Extension Cord Adapter Card with USB Riser Card

Introduction: 1.This Extender is a debug and test tool to extend PCI-Express slot from MiniCard (mPCIe) slot. Design the FFC (Flat Flexible Cable) cable for flexible use. Not only for Full-size MiniCard adapter but also Half-size MiniCard by removing extra Full-size extensions. 2.As PCI Express x1 connector is edge-free / multi-lane, x4, x8 and x16 PCIe Cards are also available. 3.This extender is designed to minimize the signal degradation effects of the extender by proven design techniques. It’s also a powerful tool for engineers and factory tests. Specification: PCI Express Mini Card Electromechanical Specification Revision 1.0 PCI Express base Specification 1.1 (Up to 2.5Gpbs) USB Specification, Release 2.0 Hi-Speed (Up to 480Mbps) System Management Bus (SMBus) Specification, Version 1.1 PCI Express Card Electromechanical (CEM) Specification 1.1 Power Supply: 3.3V (For PCIe Slot, from MiniCard), 5V (For USB, from FDD 4 pin), 12V (For PCIe, from FDD 4pin) Function: Easy Installation, Plug and Play No drivers needed for this MiniCard to ExpressCard Adapter Support Windows 2000/Server 2003/XP & XP 64-bit/Vista & Vista 64-bit/ 7 & 7 64-bit Supports both PCI Express based and USB 2.0 based MiniCard slot Supports USB 2.0 480 Mb/s data rate Miscellaneous: WAKE#, PERST# Requirements: PCI express mini card slot Warning: If MiniCard slot on the host does not support PCIe or USB interface, the interface can not be supported. Other PCIe speed of PCIe2.0 (5Gbps) is not guaranteed.

• USB Specification, Release 2.0 Hi-Speed (Up to 480Mbps)
• PCI Express Card Electromechanical (CEM) Specification 1.1
• Utilize high quality flexible FCC cable which is extremely soft and compact
• The flexible FFC cable is assembled with the based at 90¡ãfor easy mounting in the case
• High Quality Solder Points and plated Contacts for the Best Conductivity and Long Use
