Foot Valve with Filter 1-1/2" NPT, Brass Bottom Valve, Non Return Spring Vertical Check Valve to Filter Impurities, Prevent Backflow of Media for Water Pump, Irrigation, Industrial Piping System DN40
4.2 (120 items)
Limited Time Sale$15.59 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 218129082 | Release Date | 2026/05/03 | List Price | $10.40 | Model Number | 218129082 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- SINGLE-ACTING -- SYWUWV FOOT VALVE consists of a brass spring check valve and a stainless steel strainer. It is a device used to filter impurities, particles, or suspended solids in fluids. What is more, it is a kind of valve that relies on the pressure of the medium to produce the effect of preventing the backflow of the medium.
- EXPLOSION-PROOF & WEAR-RESISTANT -- The foot valve is characterized by pressure and explosion resistance and durability. It has uniform wall thickness, high wear-resistant strength. The foot valve inner wall polishing treatment, smooth surface, no scaling, no clogging, practical and durable.
- APPLICATION INDUSTRIES -- The foot valve is usually used for pump filtration of debris to prevent debris from entering the pump, thus reducing the suction resistance of the pump and lowering energy consumption. Perfect for deep well pumps, centrifugal pumps, irrigation systems, household water supply, industrial pipelines, and building water supply and drainage systems.
- EASY INSTALLATION -- The foot valves are generally installed at the bottom of the pump's underwater pipette. Installs in 3 steps: clean pipe, screw on valve, connect pump. Suitable for well jet pumps or other equipment where not only filtration is required but where the media cannot flow backwards.
- INSTRUCTION -- Filter mesh: 60 meshes. Maximum working pressure: 1.6 MPa / 232.06 psi. Maximum working pressure: 1.6 MPa / 232.06 psi. Applicable temperature: FROM -20℃ TO +150℃（FROM -4℉ TO 302℉）, Flow direction: unidirectional, media range: water, oil, non-corrosive flammable gas. Please select the appropriate size for the foot valve according to the size chart.
| UPC | 643459475823 |
|---|---|
| Size | 1 1/2" |
| Brand Name | SYWUWV |
| Unit Count | 1.0 Count |
| Valve Type | Check Valve |
| Thread Size | 1-1/2'' NPT |
| Thread Type | NPT |
| Manufacturer | SYWUWV |
| Material Type | Brass, Stainless Steel |
| Connector Type | Threaded |
| Exterior Finish | Brass |
| Number of Ports | 2 |
| Maximum Pressure | 232.06 Pound per Square Inch |
| Specification Met | ASME, ASTM, RoHS |
| Inlet Connection Type | National Pipe Tapered |
| Outlet Connection Size | 1.5 Inches |
| Outlet Connection Type | NPT |
| Manufacturer Part Number | 1 1/2 |
| Smart Home Compatibility | Not Smart Home Compatible |
