192khz Audio Converter Digital to Analog DAC - Bass and Volume Control - Digital SPDIF/Optical/Toslink/Coaxial to Analog Stereo L/R RCA and 3.5mm Jack Converter for PS3 PS4 DVD Home Cinema

Note！ 1. Before power on, you must turn the adjustmentknob counterclockwise to minimize the volume to avoiddamage to your hearing! 2. Before use, please set the audio output channel ofyour signal source devices such as DVD, TV, PS4 andother devices to SPDIF, and set the output audio formatto PCM. Introduction： This product is designed for professional audio signals,Can easily convert Coaxial or Toslink interface to RCAanalog audio interface and 3.5mm headphone jack. Theprofessional audio amplifier chip and volume adjustmentknob are designed to directly drive the headphones andadjust the output volume. The product also designed abass adjustment knob, which can easily control the bass. Features: 1.One optical fiber and one coaxial input interface.Connect to DVD, HD player and other devices 2.One RCA output interface, connected to the poweramplifier system 3.One channel 3.5mm audio output interface,Connected to headphones. 4. Eliminate the noise when there is no input signal,-and automatically mute when the non-audio signalis input. 5.Support 192kHz 24bit sampling rate. 6.Support volume adjustment 7.Support bass adjustment 8. Metal shell, anti-interference Specification: Support Audio Format: PCM Separating Degree(1KHZ): 94DB Response Frequency: 20Hz~20KHz -0.2db Signal-to-Noise Ratio(SNR): -100DB Total Harmonic Distortion(THD+N): 10Hz~20KHz 0.25-0.065% Blocking Time: 0.577Fs Sampling Rate: 32~192 KHz Bit Rate: 16~24 Bit Output Electrical Level: 7V Earphone Output Power: (RL=32Ω)30mW Output Impedance: 47 ohms Working Voltage: +5V.Maximum Voltage:6V Maximum Power Consumption: 100mA Operating Temperature Range: -10-70℃ Storage Temperature Range: -60-150 ℃Operating Humidity Range: 10% - 80%RH(NoCondensation) Storage Humidity Range: 5- 90%RH(No Condensation) Size: 76mm x70mm x16mm Gross weight:150g

• 192Khz 24-bit Sampling Rate: Supports 192Khz 24Bit optical fiber and SPDIF signal sampling rate, built-in anti-interference and no-signal input squelch circuits [Audio Format: PCM/LPCM] Plug and Play. Compatible with PS3, HD DVD, PS4, Sky HD plasma Blu-ray home theater, AV amplifiers, etc.; Note: Not compatible with 5.1 channel signals (e.g. Dolby AC3); Setting Format Steps: Setting-Sound-Audio Format-PCM/LPCM.
• Bass Adjustment: The 192KHz DAC's innovatively designed bass adjustment function delivers stunning stereo sound and heavy bass effects.
• Widely compatible with 32~600Ω headphones: Designed for gamers and music lovers, it supports all headphones in the range of 32~600Ω.
• VOLUME ADJUSTMENT: Built-in volume adjustment circuitry and control knob solves the problem of low volume when using high impedance headphones with DAC products.
• Wide range of compatibility: Portable and stylish aluminum alloy shell and gold-plated interface design, improve the overall noise immunity, clear and pure sound. Suitable for PS3, PS4, Blu-ray players, HD DVD, home theater systems and more.
