Spindle Motor, CNC Constant Power Spindle 1.5KW ER20 6000rpm Low Torque Flange Air Cooled Permanent Magnet Motor CNC Milling Machine Drilling(Set)

1.5kw ER20 Permanent magnet spindle Powerful motor / precision production / all copper coilLow speed strong distance engraving machine square air cooled motorized spindle, for customers who do not need too high speed, research and development products, can provide free testing.Strong drilling capacity6000r/minDrilling possible: 20mm/ wood 8mm/ soft metalSpindle and frequency converter systemsHigh efficiency/save time and worry: easy to use and easy to operateBenefits of frequency converter to motor:Easy to maintain cage induction motor. In addition, the original induction motor can be directly used, without the need to transform the mechanical and drive system, improve the mechanical function rate, thereby reducing power consumption, reducing loss, extending the service life of the equipment.What can the WST Series bring you?The motor is also ultra-efficient at rated full load and partial loadSpindle nodel:HDA220V7660MZ Maximun speed (rpa):6000m Rated speed(rpa):4500/225HZRated voltage(V):220V rated power (KW):1.5KW Highest frequency(Hz):300HzRated current (A)8.2A Rated torque (Na)3.2Nm Motor of pole (pole)6Ball Type:6206/6002 Shrink nozzle/chuck:ER20 Operating position:Horizcooling nethod:Air-cooled Work system:S1 long-tine vorking Weight (Kg):4.8KG==========High-concerned chemical : NoneCertification : NoneDrive : MotorMaximum Torque : 3.2NmOperating Speed : 6000rpmModel Number : 1.5kw Permanent Magnet MotorApplication : DrillingSpindle nodel : HDA220V7660MZMaximun speed : 6000Rated voltage : 220Vrated power : 1.5KWHighest frequency : 300HzRated current : 8.2ARated torque : 3.2NmMotor of pole : 6Ball Type : 6206 6002Shrink nozzle/chuck : ER20Operating position : Horizcooling nethod : Air-cooledWork system : S1 long-tine vorkingkeyword 01 : Air-cooling-spindlekeyword 02 : CNC-Spindle-motorkeyword 03 : Permanent-magnet-machinekeyword 04 : Permanent-magnet-motorkeyword 05 : Permanent-magnet-spindlekeyword 06 : Spindle-motor

• Excellent performance design to enhance user product performance experience
• Significant energy cost savings through efficient operation
• Low temperature rise, high reliability, low maintenance costs
• It is directly interchangeable with the existing asynchronous motor to realize the common stock parts and reduce the inventory cost
• The speed can be customized to provide you with a personalized solutionEnergy Efficiency Achieve IE4 (National Level Energy Efficiency)
