Brixwell 135 Degrees Square Glass-to-Glass Shower Door Hinges, Solid Forged Brass Material, Polished Brass Finish, 3-9/16" Height, 2-3/16" and 2-9/16" Plate Widths, for 3/8" to 1/2" Glass

The Brixwell 135 Degrees Glass-To-Glass Shower Door Hinges With Square Corners And Edges are designed for frameless enclosures where two glass panels meet at an angled junction. Constructed from solid forged brass with a polished brass finish, these hinges include machined stainless steel components. The hinge height is 3-9/16". The movable faceplate width is 2-3/16" with a thickness of 3/16", and the fixed faceplate width is 2-9/16" with a backplate width of 2-3/16". The hinge design incorporates dual precision wound stainless steel return springs. It features self-centering 0 degree return, a 5 degree pre-set, and self-closing from 25 degrees. Suitable for frameless glass panels of 3/8" and 1/2" thickness, each hinge is rated at 40 lbs. Two hinges can hold up to 80 lbs with a maximum door width of 30", and three hinges support 120 lbs with a maximum door width of 36". The hinges include stainless steel hex clamping screws, crosshead screws, and a hex wrench. The square cornered edges provide alignment in shower enclosures requiring consistent straight borders.

• DIMENSIONS: Hinge height is 3-9/16" with 2-3/16" movable backplate width, 2-9/16" fixed faceplate width, and 3/16" thickness, designed for 135 degree shower door hinge connections with square corners and edges.
• MATERIAL: Constructed from solid forged brass and precision stainless steel components, manufactured for shower hinge assemblies requiring angled glass-to-glass mounting layouts where square-corner hardware is applied.
• FINISH: Polished Brass surface finish provides a reflective metallic appearance, aligning with bathroom fittings and enclosure hardware components that are specified in projects using brass-colored square-edged shower hinges.
• CLOSING FUNCTION: Includes self-centering 0 degree return, a 5 degree pre-set, and self-closing from 25 degrees, supported by dual stainless steel return springs that maintain hinge balance and reliable door positioning.
• GLASS COMPATIBILITY: Configured for shower panels between 3/8" and 1/2" in thickness, consistent with frameless enclosure setups that require glass-to-glass hinges with square corners and straight surface edge alignment.
• LOAD CAPACITY: Rated at 40 lbs per hinge; two hinges support up to 80 lbs with a maximum door width of 30", and three hinges support up to 120 lbs with a maximum door width of 36", following standard shower layouts.
