Brixwell Glass-to-Glass Mount Shower Door Hinge 90 Degrees, Solid Forged Brass, Black Nickel Finish, Beveled Edges, 3/8" and 1/2" Glass Thickness, 3-9/16" Height, 3-1/8" Bottom Horizontal

The Brixwell Glass-to-Glass Mount Shower Door Hinge 90 Degrees in Black Nickel finish is designed for frameless shower door installations requiring a precise right-angle connection between two glass panels. Constructed from solid forged brass with precision-machined stainless steel internal components, this hinge provides strength and extended performance in both residential and commercial shower systems. It features dual precision wound stainless steel return springs that allow self-centering action at 0 degree return, while also enabling self-closing operation from a 25 degree door angle. The hinge comes with reversible 5-degree configuration. Designed for 3/8" (10mm) and 1/2" (12mm) tempered glass, the hinge is rated at 40 lbs per hinge. Two hinges support up to 80 lbs with a maximum door width of 30", while three hinges support up to 120 lbs with a maximum door width of 36". Dimensional details include hinge height of 3-9/16", plate width of 2-3/16", and a bottom horizontal measurement of 3-1/8". For weight reference, 3/8" glass is 5.05 lbs/sf and 1/2" glass is 6.40 lbs/sf. The beveled edge profile gives a smooth transition at the hinge connection, enhancing the fit of frameless shower designs. Hardware is included with the hinge, consisting of matching finish stainless steel hex clamp screws and a hex wrench, making installation straightforward. This hinge is non-adjustable and requires glass fabrication cutouts for mounting. Its black nickel finish coordinates with door hardware, shower hardware, glass hardware, and other fittings in bathroom projects.

• SOLID BRASS CONSTRUCTION: Formed with solid forged brass and black nickel finish, delivering dependable structure and a consistent surface that coordinates with shower hinge, glass mount, and frameless hinge component arrangements.
• SELF-CENTERING ACTION: Contains dual precision wound stainless steel return springs for self centering 0 degree return, with self closing function beginning from a 25 degree door movement to enable balanced and steady alignment.
• DOOR CAPACITY RATINGS: Each hinge is rated 40 lbs; two hinges manage doors up to 80 lbs with 30" width, while three hinges handle up to 120 lbs and 36" width, aligning with diverse frameless glass shower door structural.
• GLASS COMPATIBILITY: Suited for 3/8" (10mm) and 1/2" (12mm) tempered glass, with load estimate of 5.05 lbs/sf for 3/8" glass and 6.40 lbs/sf for 1/2" glass, ensuring proper alignment within frameless enclosure assemblies.
• DETAILED DIMENSIONS: Hinge vertical span measures 3-9/16" , plate width 2-3/16", and bottom horizontal span 3-1/8", maintaining precise allowance for glass cutout fabrication in frameless shower installations using 90 degree hardware configuration.
• GLASS TO GLASS 90 DEGREE MOUNT: Constructed for frameless shower doors requiring a 90 degree glass to glass connection, allowing stable positioning and uniform movement within shower hinge, glass hinge, and door hardware arrangements.
