IOTA 5W Emergency LED Driver for Class 2 LED Luminaires. Constant Wattage Output. Universal 120-277V Input. Auto-Sense 10-60VDC Forward Voltage. Galvanized Steel Housing, 24 in. Ni-Cad Battery
4.1 (146 items)
Limited Time Sale$140.06 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 218580221 | Release Date | 2026/05/03 | List Price | $93.38 | Model Number | 218580221 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The IOTA ILB CP05 A constant power emergency LED driver enables the existing LED fixture to deliver emergency illumination for 90 minutes in the event of a loss of normal power. The ILB CP05 A delivers 5 watts of constant power while in the emergency mode, resulting in no degradation of the emergency lighting for the entire runtime. The ILB CP05 A wires in conjunction with existing AC driver and LED array and features a forward voltage range of 10-60VDC to ensure compatibility with most any Class 2 LED luminaire. IOTA Constant Power Emergency LED Drivers allow commercial spaces to use their existing fixtures to deliver code-required emergency egress illumination, eliminating the need for additional/unwanted wall-mounted emergency lighting units. IOTA’s patented constant power design makes it easy to determine actual emergency lumen levels – simply multiply the emergency driver’s output wattage by your fixture’s ‘efficacy’ [ie. lumens per watt.] Additionally, the auto-sensing 10-60VDC forward voltage of the IOTA emergency driver automatically detects the needed voltage required by your fixture’s Class 2 [0-60VDC] LED component to provide confident system compatibility. Universal 120-277VAC input. The galvanized steel construction with wiring enclosed in dual 24 in. flexible conduit is suitable for plenum, non-air handling ceilings. Includes single-piece test switch/charge indicator accessory. UL Listed for factory or field installation.
- Wide luminaire compatibility with universal input and auto-sense Class 2 output
- Constant Wattage output delivers predictable, steady emergency lumens based on your fixture's rated efficacy (example: 500 lumens for a 100 lm/w fixture.)
- Works in conjunction with switched or unswitched fixtures
- UL 924 Listed for installation in the field or factory in the U.S. and Canada
- 120-277VAC Input, 10-60VDC output, can be installed on top or adjacent to the fixture's channel space or junction box
| UPC | 040232420276 |
|---|---|
| Color | Steel |
| Theme | Space |
| Voltage | 277 Volts |
| Wattage | 5 watts |
| Room Type | Home Office |
| Brand Name | IOTA Engineering |
| Model Name | 5W Emergency |
| Style Name | Modern |
| Unit Count | 1.0 Count |
| Fixture Type | Non Removable |
| Light Source | LED |
| Manufacturer | Acuity Brands |
| Model Number | ILB CP05 A M5 |
| Power Source | Battery Powered |
| Material Type | Metal |
| Mounting Type | Ceiling Mount |
| Item Type Name | 5W Emergency LED Driver for Class 2 LED Luminaires. Constant Wattage Output. Universal 120-277V Input. Auto-Sense 10-60VDC Forward Voltage. Galvanized Steel Housing, 24 in. Ni-Cad battery |
| Shade Material | Alloy Steel |
| Number of Items | 1 |
| Specification Met | UL |
| Light Fixture Form | Wall |
| Included Components | 5W Emergency LED Driver for Class 2 LED Luminaires. Constant Wattage Output. Universal 120-277V Input. Auto-Sense 10-60VDC Forward Voltage. Galvanized Steel Housing, 24 in. Flexible Conduit either side , Ni-Cad battery. UL Listed. |
| Number of Light Sources | 2 |
| Manufacturer Part Number | ILB-CP05A |
| Manufacturer Warranty Description | 5-year limited. |
