HAZET 61101CT High Precision Preset Torque Wrench 1 Piece

Additional product details: Trigger accuracy ± [%]: 2. Scale division [Nm]: 0.5. Length: 335 mm. Usable width: 32 mm. Thickness: 14.5 mm. Surface: hard chrome plated. DIN/ISO: 1174-1. DIN/ISO: 3120. DIN/ISO: 6789:2003 (D). Made in Germany. Weight [g]: 560 Technical information: ± 2% accuracy from scale value (in actuation direction). High-precision premium torque tools - for the highest demands. Robust and durable hard chrome-plated steel tube construction in slim design. Safe storage in safe box with viewing window. Safe: Haptic (short-way release). Acoustic (bend element). Optical (models with signal button). User-friendly reversible ratchet. Service-friendly (Repair She repair repair -She sets for customer-oriented self-assembly). Integrated switching lever. Adjustment of the desired torque value quickly and safely by turning the handle. Rotary knob for additional locking of the adjustment. Ergonomically shaped handle with collar reduces risk of slipping or injury. Exactly fine scale division 6121-1 CT – 6123-1 CT: switch lever with freewheel function. 1 Hazard and malfunctions with calibration certificate and serial number. Surface: hard chrome-plated DIN EN ISO 6789-2:2017, DIN 3120, ISO 1174-1. Made in Germany. Output: square 10 mm (3/8 inch). Dimensions / length: 335 mm. Net weight (kg): 0.56 kg. Nm min-max: 5 – 6 0 Nm. Tolerance: 2 %. Scale division (Nm): 0.5 Nm. Effective length of the torque wrench min. - max. L1 mm: 264.42 – 247.92 Nm. Actuation force min. - max. kg: 1.9 – 24.7 kg. Number of teeth: 30 (actuation angle 12°). Head thickness a: 14.5 mm. Head width b: 32 mm. No more turning back: with the HAZET torque wrenches of the 5000 and 6000 series, it has been proven in long-term continuous tests that turning back to the smallest Skalenwert not required

• Torque wrench - system 6000 CT (3/8 inch), Nm min: 5 Nm, Nm max: 60 Nm
