Meanwell LRS-150-12 150W 12V 12.5A LED Strip AC/DC LED Power Supply Driver
4.2 (60 items)
Limited Time Sale$14.60 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 218916592 | Release Date | 2026/05/03 | List Price | $9.73 | Model Number | 218916592 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
High efficiency, long life and high reliabilityminiature size and high power densityHigh operating temperature up to 70 ° Celectrolytic capacitors Extended Life from 105 ° Ceasy installation with screw terminalsAdjustable output voltage for the types double output at output 1, from -5% to + 10%Dual outputs have a minimum load requirement, see output current data (data sheets). The total load must not exceed the rated output powerHarmonic current compliance to EN 61000-3-2EMC meets EN 55022 Class BProtection against over-voltage, overload and short circuit
- Output Voltage: 12V DC, 10.2 ~ 13.8V DC, Output Current: 12.5A, Maximum Output Power: 150W, Protection: overload, overheating, voltage rise, short-circuit, Mounting: recessed, Working temperature: -30 +70°C
- Property: 100-240 V
- Voltaggio in uscita: 12 VOLT DC
- Lunghezza in mm: 159
- Larghezza in mm: 97
| Brand | MEAN WELL |
|---|---|
| Color | Silver |
| Amperage | 12.5 Amps |
| Form Factor | ITX |
| Manufacturer | Mean Well |
| Model Number | LRS-150-12 |
| Input Voltage | 85 Volts (AC) |
| Maximum Power | 150 Watts |
| Output Current | 12.5 Amps |
| Output Voltage | 12 Volts |
| Output Wattage | 150 Watts |
| Mfr Part Number | LRS-150-12 |
| Specification Met | EMC |
| Enclosure Material | Alluminio |
| Connector Type Used on Cable | Screw Terminal Block |
