10pcs 4 Pin LED Strip Corner Connector for SMD 5050 RGB LED Strip Light 10mm Wide LED Tape Connector Solderless RGB 5050 LED Ribbon L Shape Connector Right Angle Adapter

These corner connectors are compatible with both non-waterproof and waterproof SMD 5050 RGB LED strips that are 10mm in width and have 4 copper contacts at every cutting line. Precautions: When you cut your LED strip into 2 LED strips, you should cut very carefully along the cutting line, to make sure the area of the copper contacts on the 2 LED strips are the same. (not a bigger area of copper contacts on one LED strip, and a smaller area of copper contacts on the other LED strip.). If the area of the copper contacts on the LED strip is too small, the 4 electrical conductors in the connectors can not totally touch the 4 copper contacts on the LED strip, and there will be poor electrical conductivity. As a result, you may get 2 different colors or even get no colors at all.Installation Instructions: 1. Ensure your LED strip is 10mm wide and has 4 copper contacts at the cutting line. 2. Carefully cut your LED strip along the cutting line. Do not tear off the paper on the back of the LED strip before finishing the connection. Just insert the paper and the LED strip together into the connector. This will be easier to insert the LED strip into the connector without bending the LED strip into damage, and the connection will also be more stable. 3. Open the cap of the connector. 4. If you use a non-waterproof LED strip, please insert the LED strip into the connector. Make sure the 4 copper contacts on the LED strip are under the 4 electrical conductors in the connector; If you use a waterproof LED strip, please first remove the waterproof silicone around the cutting line, then insert the LED strip into the connector. Make sure the 4 copper contacts on the LED strip are under the 4 electrical conductors in the connector. 5. Close the cap, and check whether the connector works well. 6. Tear off the paper on the back of the LED strip to stick the LED strip, but please reserve the paper that has already been in the connector. Note: Please make sure that the positive poles of your LED strips at both ends of the connector are on the same one channel. Please make sure the arrow marks on your cable, your LED strip and your controller are on the same one channel. Tips: The L-shape connectors can be used on both left corners and right corners. Don't care about the mark (+,R,G,B) on the L-plate or the mark (+,-) on the connector. You just need to make sure that the positive poles of your LED strips at both ends of the connector are on the same one channel. Solutions: If the LED strips flicker or do not light up, please follow these steps: 1. Take off the LED strip from the connector. 2. Open all caps on the connector. 3. Use a thin and hard object to simultaneously press hard on both ends of each electrical conductor in the connector, to bring the electrical conductor down to the lowest position. Make sure the electrical conductor can touch the surface of the bottom of the connector without any pressure. In this way, the 4 electrical conductors in the connector can fully touch the 4 copper contacts on the LED strip, ensuring good electrical conductivity. 4. Insert the LED strip into the connector. Package includes: 10x L-shape 4 pin connectors

• APPLICATION: Suitable for both Waterproof and Non-Waterproof SMD 5050 RGB LED strip lights (10mm in width). Not for SMD 3528 RGB LED strip lights (8mm in width). Please remove the waterproof material on the surface around the cutting line first when using these connectors on your waterproof RGB LED strips.
• FIREPROOF MATERIAL: Made from fireproof material, the L shape 4 pin connectors can withstand high temperature. The plastic is thick and solid and will not be broken easily.
• EASY TO USE: Simple but effective, tool free, easy installation by clipping system, making a neat and good looking layout for your LED strips to turn around the corners. Couldn't be easier to use these connectors for LED strips to turn around corners.
• VERY PRACTICAL: With these L-shaped connectors, you can avoid twisting your LED strips which potentially damages your LED strip. The 4-channel PCB chip with 2 easy-clasp connectors makes a seamless connection for your RGB LED strips.
• Package includes 10pcs L-shaped connectors for 10mm wide 4-Pin RGB LED Strip.
