220V Heat Shrink Tunnel Packaging Machine, 4500W Thermal Shrink Wrapping Machine with Mesh Conveyor Belt, Dual-Zone Temp Control, 30 * 15cm Max. Shrink Size, for PVC POF Film, BS-3015

Product Parameter:Item Number: 021494Power: 4500WVoltage: 220VMaterial: Iron spray paintMax. Shrink Size: 11.81*5.9 in (30*15 cm)Max. Feeding Weigh: 10kg (22 lbs)Conveyer Speed: 0-32.8/ft (0-10m/min)Shrinking Membrane:PVC: Thickness 0.02 - 0.06 mm; heating time 5 - 10 s; temperature 110 - 130 ℃POF: Thickness 0.02 - 0.06 mm; heating time 5 ~ 12 s; temperature 120 - 180 ℃Precautions for Product Use:1. For high-power machines, we recommend connecting directly to the main power supply to ensure greater safety, reliability, and stable voltage. (We provide a wiring video—if you're unsure how to connect it, please contact us for assistance.)2. After powering on and setting the temperature, wait 10–15 minutes for the heating tube to reach the set temperature and complete the shrinking cycle.Product Safety Precautions:1. Always follow the "safety first" principle and operate the machine correctly.2. Ensure the machine is connected only to the correct power supply specifications.3. Do not insert your hands into the machine while it is operating—hot surfaces can cause burns. After turning it off, wait until the interior has fully cooled before touching any internal parts.

• 【Mesh Conveyor Belt】This shrink machine is fitted with a metal mesh conveyor belt, ideal for small and lightweight items. The mesh structure supports fast heat transfer and even bottom heating, making it suitable for products with limited bottom contact area. It is designed for efficient shrink wrapping of appropriately sized goods, while larger or heavier products can be matched with chain conveyor models for better results.
• 【Quartz Far-Infrared Direct Heating Performance】Equipped with quartz far-infrared heating tubes, the machine delivers stable and focused thermal energy for PVC and POF film shrinking. It supports a wide range of film thickness from 0.02–0.06 mm with matched temperature and time settings, achieving consistent and tight contraction effects for multi-piece articles and tray packaging.
• 【Intelligent Adjustable Control System】The intuitive control panel supports independent upper and lower temperature adjustment and stepless conveyor speed regulation from 0–10 m/min. Electronic variable speed control and enhanced temperature feedback maintain stable working parameters, allowing flexible setup for different product sizes and packaging film requirements.
• 【Safety & Stable Electrical System】A overload protector is integrated to maintain safe operation by managing overheating and overcurrent conditions. The core electrical control box includes a cooling fan for sustained component performance, improving overall reliability and extending the machine's service life.
• 【Efficient Heat Dissipation】Designed with exhaust and heat dissipation holes, the machine quickly releases internal heat during operation. This effective thermal management reduces component wear from high temperatures, supporting longer working cycles and maintaining consistent performance for daily packaging tasks.
