HDMI 5.1 Audio Converter Decoder DAC DTS AC3 FLAC APE 4K*2K HDMI to HDMI Extractor Converter Splitter Digital SPDIF ARC

parameter： HDMI Version：HDMI1.4 &HDCP 1.4 HDMI Baudrate：10.2Gbps HDMI DDC：5Vpp(TTL) DSPsample：32-192 KHz DigtalLevel：0.1-1.5Vp-p S/N@0dB：≥90dB Frequency：20Hz-20KHz lnput：AC100V-240V；50/60Hz Output：DC 12V/1A HDMI Bandwidth：340MHz HDMI TDMS：0.5-1.5Vpp(TTL) HDMI Cable length：≤20m standard cable DSP Baudrate：16-24 Bit 5.1ch output Level：≥1.5V RMS(1kHz@0dB) THD：≤0.03% MAX Power：≤200mA Operating Humidity：10-90%RH(non-condensin) Srorage Humidity：5-95%RH(non-condensin) Product Weight：370g

• Audio decoder: This digital audio converter not only supports AC-3/ DTS/ LPCM/ PCM/ RAW, but also can decode Dolly AC-3/ DTS digital audio into analog audio.
• 5.1CH DIGITAL AUDIO: This audio decoder can automatically convert HDMI input to 5.1-channel analog audio output, and automatically decode AC-3/DTS (LPCM/PCM/RAW) input signals without any operation.
• Adjustable volume: Equipped with a volume knob to adjust the volume, allowing you to adjust the output volume. It can eliminate noise when there is no signal input and automatically mute the sound when there is no audio signal input.
• 192KHZ: Supports 32KHz, 44.1KHz, 48KHz, 96KHz and even 192KHz sampling rates (many only support 96KHz), providing high sound quality. It also supports 24-bit SPDIF incoming bitstream for left and right channels.
• Wide compatibility: With SPDIF/Coaxial input and 2.0/5.1CH RCA + 3.5MM audio output, suitable for Blu-ray, DVD, PS3, PS4, HDTV, etc. (Note: RCA output should be connected to the amplifier first, but cannot be directly connected to the speaker .)
