AC Compressor with Clutch Fits for Honda Fit 1.5L 2009-2013 Replaces 38810RP3305 38810RP3A01

Specifications： Compressor Type: TRSE07; Oil Type: PAG46; Refrigerant Type: R134A; Pulley Grooves: 5; Clutch Included: Yes; Oil Prefilled: 150 ML The daily maintenance precautions for automobile air conditioning compressors are as follows: I. Regular inspection: 1. Check the appearance - Check the appearance of the compressor frequently to see if there is any obvious damage, oil leakage or air leakage. - Check whether the connecting pipes and joints are loose, worn or leaking. Make sure that the pipes are firmly connected without looseness or leakage. 2. Check the pressure - Use professional pressure detection tools regularly to check whether the pressure of the air conditioning system is normal. Generally speaking, the pressure on the high-pressure side of the automobile air conditioning system is between 1.37-1.57MPa, and the pressure on the low-pressure side is between 0.15-0.25MPa. If the pressure is too high or too low, it may indicate that there is a problem with the compressor. II. Correct use: 1. Avoid frequent start and stop - Try to avoid frequent start and stop of the air conditioning system, as this will cause a large load on the compressor and affect its service life. - If you need to temporarily turn off the air conditioning, you can increase the temperature or reduce the air volume instead of directly turning off the air conditioning system. This can reduce the number of starts and stops of the compressor and extend its service life. 2. Control temperature and air volume - Set the temperature and air volume of the air conditioner reasonably to avoid setting the temperature too low or the air volume too high. - Avoid running the air conditioner in maximum cooling mode for a long time. If the temperature in the car has been reduced to a comfortable level, the temperature and air volume can be adjusted appropriately to reduce the working intensity of the compressor. III. Keep it clean: 1. Clean the condenser and evaporator Regularly cleaning the condenser and evaporator can improve the cooling efficiency of the air conditioner, reduce the working time of the compressor, and extend its service life. For example, professional cleaning agents and cleaning tools can be used for cleaning to remove dust, dirt and debris on the surface. - Be careful not to damage the fins (heat sink) of the condenser and evaporator during cleaning to avoid affecting the heat dissipation effect. 2. Keep the car clean - Keeping the car clean and reducing the entry of dust and debris can reduce the load of the air conditioning system and extend the service life of the compressor. Regularly clean up debris, garbage and dust in the car, use a vacuum cleaner to clean the carpet and seats, and keep the air in the car fresh. IV. Pay attention to maintenance: 1. Regularly replace refrigerant and refrigeration oil 2. Check the drive belt Pakage includes: 1* AC Compressor with Clutch Note: Please check the OE number and model number carefully before purchasing to make sure it is what you need. We provide you with complete after-sales and pre-sales service, any questions and needs please contact us in time, we will reply you within 24 hours and give you the most sincere advice!

• Function: The main functions of automobile air-conditioning compressors are as follows: compressing refrigerant: increasing refrigerant pressure and promoting refrigerant circulation; regulating refrigeration capacity: adjusting power according to demand and cooperating with other components to achieve temperature control; protecting the air-conditioning system: preventing refrigerant backflow and maintaining system pressure stability
• Replacement OE Part Numbers: 38810RP3305, 38810RP3A01, 38810RP3A02, 38810RP3A03, 38810RP3A04
• Common faults of air-conditioning compressors are as follows: stuck: the compressor cannot rotate; leakage: there are two types of leakage: oil leakage and air leakage; poor operation: compression produces higher temperature vapor, so the back and forth circulation will burn the refrigeration oil and cause the compressor to be scrapped; abnormal noise: mainly caused by slipping when the clutch is engaged, or caused by the drive belt being too loose or worn; short circuit or open circuit
• Compatiblity: Fits for Honda Fit 2009-2013 1.5L
• Service: Thank you for your support, if you have any questions, please contact us and we will reply within 24 hours. Pls CHECK your OE number and model before buying
