USA Lab 45CFM UVP-45 Corrosion Resistant 2-Stage Vacuum Pump - USAlab

Our new line of corrosion resistant UVP-34 34 cfm vacuum pumps provide superior quality that can compliment multiple applications. These pumps are designed for reliable, long term use at 0.3 microns and a powerful pumping speed of 34 cfm. Each 2-stage vacuum pump comes standard with an exhaust oil mist filter and all parts needed to connect to any system for immediate use. Our UVP-34, or UVP-45 45 CFM vacuum pump are great for any laboratory application, including short path distillation, vacuum ovens, and many more. Upgrade today and get one of the most superior vacuum pumps on the market at an affordable price. - Allows users to control the gas ballast for multiple vacuum levels. - Corrosion-resistant pump vanes for premium reliability. - Low noise level and noise-dampening rubber feet. - Internal check-valve, preventing accidental back-flow. - Easy to change oil mist filter. - Large oil reservoir. -MANUAL- SPECIFICATIONS Model UVP-34 UVP-45 Pumping Speed (60Hz) 34 cfm 45 cfm Ultimate Total Pressure Gas Ballast Close 4x10-2 Pa (3.0x10-4 torr) 0.3 Micron Ultimate Total Pressure Gas Ballast Open 8x10-1 Pa (6x10-3 torr) 6 Micron Power Supply 3 Phase (240V, 60Hz) Power Rating(kW) 1.5 2.2 Inlet/Exhaust Flange KF40 Oil Capacity (L) 3.3~4.5 Ambient Temperature (℃) 10~40(℃) Noise Level (dB) 62 65 Weight (kg) 21 30 External Dimensions 724x241x317MM 750x241x317MM 28.5x9.5x12.5" 29.5x9.5x12.5" Certification CE Warranty 2 Year PACKING LIST Model UVP-34 UVP-54 Main Vacuum Pump 1 1 KF40 x 3/8" Barb 1 1 KF40 Clamp 2 2 KF40 O-Ring 2 2 Oil Mist Trap 1 1 Quart of Oil 1 1 Manual 1 1 For Technical Support, Questions, or Other Issues Please Email or Call Us!

• Our new line of corrosion resistant UVP-34 34 cfm vacuum pumps provide superior quality that can compliment multiple applications
