3 Row Radiator For Dodge B100 B200 B300 D100 D200 D300 W100 W150 W200 3.7L l6/5.2L 5.9L 6.6L 7.2L V8 GAS 1976-1978 76 77 78 Radiador + Shroud + Fan + Relay

FitmentFor 1976-1978 Dodge B100 B200 B300 5.2L 5.8L V8 GasFor 1976-1978 Dodge D100 D150 D200 D300 3.7L l6/5.2L 5.9L 6.6L 7.2L V8 GasFor 1976-1978 Dodge W100 W150 W200 W300 5.2L 5.9L V8 GasRadiator DetailsRow Count: 3 RowUpper Inlet: 1.5" located on driver sideLower Outlet: 1.77" located on passenger sideSurface Finish: Aircraft Grade Raw AluminumOEM style brass petcock drainCNC machined filler neck and capFans SizeMaximum Fan CFM: 2000±200Fan Diameter: 16.050 inchesThickness: 2.790 inchesNumber of Blades: 10 bladesMaximum Fan RPM: 2,250 rpmBlade Material: PlasticAmp Draw: 12.70 ampsIncludes the Mounting Tabs for an Easy Zip Tie InstallationThermostat KitRed + connect directly to battery.White wire to ignition switch power source.Black goes to thermos switch.Blue wire goes to the Fans.Part NumberManufacturer Part Number: 4032889, 4032967, 4036067, 4036076, 4036094, 4036927, 8010210, 8011586Interchange Part Number: 3736937, 3736939, 3736941, 3736944, 3820937, 3820939, 3820992, 8010889Other Part Number: 3893460, 4030316, 4030317, 4030318, 4030319, 4030373, 4032887, 4032888

• For 1976-1978 Dodge B100 B200 B300 5.2L 5.8L V8 Gas; For 1976-1978 Dodge D100 D150 D200 D300 3.7L l6/5.2L 5.9L 6.6L 7.2L V8 Gas; For 1976-1978 Dodge W100 W150 W200 W300 5.2L 5.9L V8 Gas
• Core Size: 1.73" T x 18.03" H x 25.9" W; Overall Size: 24.1" H x 30.15" W; Inlet/Outlet Diameter: 1.5"/1.77"
• High Performance. Full AA5052 Aircraft Aluminum craftsmanship radiator & exclusive tube design that dramatically increases cooling efficiency by up to 30%~45%, strong and durable, 100% welded by TIG, No Epoxy. 100% Leak Tested
• Easy to Install. Meticulously built to superior OE standards a precise fit, direct bolt-on replacement. No Drilling or Modifications Needed Installation
• Crafted by our professional team using the highest-grade materials for exceptional longevity.
